Automatic - Recovery, Reclaim, Vacuum Pulling, Oil Charge, Charging

  • Large display
  • Equipped with 2 special filters
  • All modes can be operated individually
  • Equipped with a heat exchange type oil separator
  • Conventional refrigerant can and oil can are applicable



Item C60G C60GS
Applicable Refrigerant R134a
Auto Operating Cleaning : • recovery / reclaim • vacuuming • charging Cleaning : • recovery / reclaim • charging
Voltage 100V (50/60Hz)
Compressor 375W Oilless
Weight 83kg 75kg
Operating Temperature 5~40°C
Vacuum pump Exhaust rate :
51 • 57L/ min (50/60Hz)
Ultimate vacuum :
2.0 Pa abs. (15 micron)
Equipped Cylinder 6L cylinder (stationary)
Oil Separator Separating system : Heat exchang type / Capacity :900mL
Weighing Method by Road cell
Standard Accessories High and low pressure charing hose (2.5m) ×1 each, Thermometer,
Filter dryer×2, High and low pressure quick joint×1 each
